BN15-CPS Universal Power Supply
BN15-CPS series universal power supply comprise 9 models, including: BN15-EPS200V, BN15-EPS300VE, BN15-600HC, BN15-1000C, BN15-1600C, BN15-ECP3000, BN15-ECPT300 the maximum output voltage varies from 200V to 3000V, can widely cover most electrophoresis experiments, Bionova can provide different types of power supplies for experiments with different uses.
1. Molding shell, touch keys, dual core microprocessor intelligent control
2. Indicate the preset value and the actual output value at the same time
3. It can store 10 electrophoresis methods
4. With automatic memory function
5. With standard, timing operation function
6. With constant voltage, constant current, constant power, misoperation,
fault intelligent prompt functions
7. Automatic detection of no-load, over-load, short circuit, rapid resistance change,
ground leak and system overheating.
| Type of Output: | Constant-Voltage, Current or Power |
|---|---|
| Increment: | 1V, 1mA, 1W |
| Timer Range: | 1min~99hr, 59min |
| Display: | LCD display with backlight |
| Output jacks: | Four sets of output jacks |
Technical specifications for BN15-CPS series Universal Power Supply
| BN15-200VC | BN15-300VC | BN15-300VCH | BN15-600C | BN15-600HC | BN15-1000C | BN15-1600C | BN15-ECP3000 | BN15-ECPT300 | |
|---|---|---|---|---|---|---|---|---|---|
| Voltage range | 5~200 V | 5~300 V | 5~300 V | 10~600 V | 10~600 V | 30~1000 V | 20~1600 V | 20~3000 V | 20~3000 V |
| Current range | l~2000mA | l~400mA | l~1500mA | l~500mA | 1~l000mA | l~500mA | 1~l00mA | l~200mA | l~200mA |
| Power range | 1~200 W | l~120 W | 1~450 W | 1~300 W | 1~300 W | 1~300 W | l~160 W | 1~200 W | 1~200 W |
| Type of control | Constant V, Constant I and Constant P | Constant V, Constant I and Constant P | Constant V, Constant I and Constant P | Constant V, Constant I and Constant P | Constant V, Constant I and Constant P | Constant V, Constant I and Constant P | Constant V, Constant I and Constant P | Constant V, Constant I and Constant P | Constant V, Constant I and Constant P |
| Display type | LCD screen with backlight | LCD screen with backlight | LCD screen with backlight | LCD screen with backlight | LCD screen with backlight | LCD screen with backlight | LCD screen with backlight | LCD screen with backlight | LCD screen with backlight |
| Output jack | Four sets | Four sets | Four sets | Four sets | Four sets | Four sets | Four sets | Four sets | Four sets |
| Storage function | Store 10 methods | Store 10 methods | Store 10 methods | Store 10 methods | Store 10 methods | Store 10 methods | Store 10 methods | Store 10 methods | |
| Programming method | No | No | No | No | No | No | No | No | No |
| Timing function | 1min-99h59min | 1min-99h59min | 1min-99h59min | 1min-99h59min | 1min-99h59min | 1min-99h59min | 1min-99h59min | 1min-99h59min | 1min-99h59min |
| V-hr function | No | No | No | No | No | No | No | No | No |
| Pause control function | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Power recovery function | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional |
| Automatic memory function | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Automatic shutdown function | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Intelligent prompt functions | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Non-proliferation field function | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional |
| Temperature Detection function | No | No | No | No | No | No | No | No | Yes |
| Safety Performance | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Molding machine casing | Yes | Yes | Yes | Yes | No | No | No | No | No |
| Volume (L x W x H) | 280x237x118 (mm) | 280x237x118 (mm) | 280x237x118 (mm) | 280x237x118 (mm) | 263x275x125 (mm) | 263x275x125 (mm) | 263x275x125 (mm) | 263x275x125 (mm) | 263x275x125 (mm) |
| Weight | 3.2 kg | 3.2 kg | 3.2 kg | 3.2 kg | 4.4 kg | 4.6 kg | 4.6 kg | 7.0 kg | 7.0 kg |
